13.3 Inch TFT LCD Display with Projected Capacitive Touchscreen, EDP TFT LCD 13.3 Inch 1920*1080 Resolution

13.3-Inch TFT LCD Display with Projected Capacitive Touch, EDP TFT LCD Display 13.3-Inch FHD 1920×1080 Resolution

The SFTO1330JD-7057A-CT TFT LCD display features a 13.3-inch color active matrix TFT LCD module utilizing amorphous silicon TFTs (Thin Film Transistors) as active switching devices. With a diagonally measured active area of 13.3 inches, this display boasts Full-HD resolution (1920 horizontal by 1080 vertical pixel array). Each pixel comprises red, green, and blue dots arranged in a vertical stripe, enabling the module to display 16.7 million colors with a color gamut of 72%. Additionally, the LED driver for backlighting is integrated into this model.

Operating with a 1920x3x1080 dot panel and displaying 16.7 million colors, the SFTO1330JD-7057A-CT TFT LCD display utilizes an eDP (Embedded Display Port) Ver1.2 interface and requires a +3.3VDC supply voltage for TFT-LCD panel driving. This display incorporates color filters for excellent color performance, resulting in brighter and clearer pictures, making it ideal for multimedia applications. Optimal viewing angles are achieved in all directions, and it does not require a backlight-driving LED controller. The EDP transfer rate specification is 2.7Gbps/2 lane 8bit.

Key Features:

• Reserve Type
• eDP interface
• High-speed response
• 6-bit (Hi-FRC) color depth, displaying 16.7 million colors
• Incorporated edge type (LED) backlight
• Compatible with RGB98% and NTSC45% (NTSC72% also available)
• High luminance and contrast ratio, low reflection, and wide viewing angle
• Data Enable (DE) only
• RoHS and Halogen-free
• TEO 6.0, ES6.0 Compliant
• Gamma Correction
