TFT LCD Factory Supply 320×480 Dots 3.5 Inch TFT Display, 3.5″ PCAP Touchscreen Display HVGA MCU Interface

Unveiling Our 3.5-Inch TFT Touch LCD HVGA 320×480 with MCU Interface PCAP TFT Touch LCD

Product Snapshot:

• LCD Dimensions: 3.5 inches TFT
• Resolution: HVGA 320×480
• Viewing Angle: 12 O’clock
• Outline Dimension: 54.48×84.71x 2.2 mm
• LCD Driver IC: ILI9488
• LCD Interface: 3SPI+RGB16 Bit
• Temperature Range: Top -20°C to +70°C; Tst -30°C to +80°C
• Touch Panel: Projected Capacitive Touch Screen
• CTP Structure: G+F+F
• CTP Driver IC: GSL915

Product Highlights:

• The SF-TC350H-8826A-CT2 TFT LCD module boasts a 3.5-inch diagonal size, 320xRGBx480 resolution, presenting a full-color TFT LCD display with a Projected Capacitive Touch Screen (PCAP).
• Supporting a 3SPI+RGB16 Bit Interface, the SF-TC350H-8826A-CT2 model features dimensions of 54.48×84.71 mm and an Active area size of 48.96 x 73.44 mm.
• Integrated with an ILI9488 controller on the module, SF-TC350H-8826A-CT2 operates within a logic supply voltage range of 2.6V to 3.3V.
• Functioning smoothly within temperatures ranging from -20℃ to +70℃, with storage temperatures spanning from -30℃ to +80℃.
• SF-TC350H-8826A-CT2 is optimized for portrait mode, offering a luminance of 300 cd/m2. For landscape mode utilization or increased luminance, please reach out to us for specialized technical assistance.
• The PCAP cover glass of SF-TC350H-8826A-CT2 is customizable, as is the FPC.

Applications: This 3.5″ TFT LCD Module is ideally suited for GPS devices, POS terminals, cash readers, scanners, home automation systems, conference phones, analyzers, home appliances, security systems, and more.

Quality Assurance:

• Each piece undergoes triple 100% testing to ensure top-notch quality.
• With a QA manager boasting over 14 years in the LCD industry and key manufacturing and QA operators with 7-8 years of experience, our team ensures professional and reliable quality control.
• Any defects are eligible for returns and replacements.
• All products are ROHS compliant.

Customer Service:

• Before finalizing contracts, we provide detailed analysis and professional solutions based on customer project information.
• Expect prompt responses to inquiries regarding our products or pricing within 24 hours.
• We keep customers informed about production processes and facilitate quality checks if needed.
• A one-year warranty accompanies our LCD displays post-delivery, ensuring defects can be returned and replaced during this period.
• Complimentary technician training at our factory is available before delivery.
• We prioritize customer value creation and offer various support channels such as con-call meetings, online technical assistance, or local on-site help to cater to diverse needs.

FAQ:

1. How do I place an order?

Please provide clear requirements, enabling us to promptly send an offer for your order. For detailed discussions or design inquiries, feel free to contact us via email or phone.

1. What types of displays do you offer?

We provide a range of displays including TFT color LCD modules, monochrome LCD modules, OLED LCD modules, LCD modules with digital frames, and Android Tablets. Our solutions cater to indoor and outdoor, industrial, and commercial applications, with both standard and customized designs available.

1. What is the warranty period?

We offer a 1-year warranty, allowing for returns and replacements of any defects.

1. What are your delivery terms?

We accept EXW, FOB, FCA, etc., enabling you to choose the most convenient or cost-effective option.
